Frequency Conversion Heat Pump Heating and Cooling
1. Using dc frequency conversion + EVI jet increase enthalpy heat pump compressor at low temperature, has thecharacteristics of high efficiency and energy saving, safe and reliable;
2. Low noise, low frequency startup, the grid impact small;
3. Low environmental protection using R410A refrigerant;
4. Broadband operation, no frequent downtime, more energy saving, high Frequency Conversion Heat Pump Heating and Cooling is strong, system failure to reduce heat;
5. Intelligent cream, cream defrosting, frost-free except;
6. Smart union, a remote control.
Circumstance Tempreature
-7 to 43℃
Power Supply
220V 50Hz
Electrical Shock Grade
I
Waterproof Grade
IPX4
norminal 1 Rated Heating Capacity
13kw
norminal 1 Rated Consuming Power
3.9kw
norminal 2 Rated Heating Capacity
9.1kw
norminal 2 Rated Consuming Power
3.7kw
Low tempreature heating capacity
7.6kw
Low tempreature Consuming Power
3.6kw
IPLV(H)
3.21 W/W
norminal cold capacity/consuming power
9.1kw / 3.15kw
IPLV(H)
4.23 W/W
Maximum Consuming Power
5.3kw
Maximum Working Current
24A
Circular Water Flow
1.55m³/h
Water Side Pressure Loss
27kPa
