Garri Processing Plant Garri Processing Line
Garri Processing Plant Garri Processing Line VIDEO
Features of Garri Processing Plant Garri Processing Line
The automatic garri processing line is a series of cassava processing machines to make white garri(gari) or yellow garri(gari) from the fresh cassava roots. The whole set of garri production line includes the cassava washing and peeling machine, Cassava Grating Machine, hydraulic cassava mash dewatering machine, cassava grinding machine, Garri Frying Machine, Garri Sieving Machine and gari packing machine. All these garri processing equipment can be different models and various working capacities for users to choose in making garri powder under different cassava flour processing requirements.
How how to make starch from cassava?
To make good garri(gari) from the fresh cassava roots, especially the mass production of fine garri powder, a variety of cassava processing machines are needed as the support. The entire garri production process including cassava washing and peeling, cassava grating, cassava dewatering, milling and sifting, garri roasting, garri screening, and garri packaging.
Steps in garri processing line
1. Cassava washing and peeling machine
The cassava peeling and washing machine is mainly composed of motors, transmissions, and brush rollers. It is taking the characteristics of root and tuber processing machinery at home and oversea. It uses the principle of brush friction and is widely applicable to round, oval fruits and vegetables such as ginger , Carrot, potato, potato, sweet potato, and other root potato vegetables for cleaning and peeling, can also be walnuts, ginkgo and other dried fruit materials such as peeling and shelling. It is an ideal equipment for agricultural product processing like Garri processing.
Cassava Peeling MachineTechnical Parameter:
Model No.
GD-BP-1000
GD-BP-1500
GD-BP-2000
GD-BP-3000
Machine Material
Stainless steel
Stainless steel
Stainless steel
Stainless steel
Capacity
500kg/hour
1000kg/hour
1500kg/hour
2000kg/hour
Voltage
380V & 50/60Hz 3Phase
Power
3.00kw
4.00kw
4.00kw
5.50kw
Rotate speed
can be adjusted
can be adjusted
can be adjusted
can be adjusted
Inner diameter of rotary drum
800mm
800mm
800mm
800mm
Inner length of rotary drum
1000mm
1500mm
2000mm
3000mm
Weight
400kg
500kg
900kg
1200kg
Dimension(L×W×H)mm
2. Cassava grating machine
To crush the peeled cassava into small pieces or cassava mash, the cassava grating machine can be a good helper. The cassava grater has two pairs of inner crushing rollers in its grating chamber. The smaller crushing roller can do coarse crushing of the cassava, and the bigger one will do further fine grating of the cassava. We can use a conveyor for automatic adding of cassava for grating or put the cassava manually to the crushing machine inlet during the garri processing line.
Cassava Crusher Technical Parameter:
Model No.
GD-GG-1000
GD-GG-3000
GD-GG-5000
Machine Material
Stainless Steel
Stainless Steel
Stainless Steel
Capacity
1000-2000Kg/Hour
3000-4000Kg/Hour
5000-6000Kg/Hour
Voltage
380V & 50/60Hz 3Phase
380V & 50/60Hz 3Phase
380V & 50/60Hz 3Phase
Power
7.5KW
11KW
15KW
Weight
250KG
350KG
450KG
Dimension(L ×W ×H)
1300×700×1400mm
1300×1000×1400mm
1300×1300×1400mm
3. Cassava mash fermenting
Before the cassava mash dehydration, we should do fermentation of the cassava slurry to increase the good tastes of the garri and improve various probiotics, protein, and amino acid content. We can use the clean polythene sack to divide the cassava mash into several bags and lay them on the rack for 1-2 days’ fermenting. The milky water will drain freely from the bags and we can use the container to collect them for extracting the cassava starch. Do not ferment the cassava slurry for a too long time, because long time fermenting will make the cassava mash become very hard.
4. Cassava dewatering machine:
The common used cassava mash dewatering machine for garri production line is the hydraulic press equipment. When doing cassava dehydration, we should put the bagged cassava mash(which has been fermented) into the press barrel, then push the press button of the cassava dewatering machine. The press force comes from the hydraulic power of this dehydrating machine. And the pressed milky liquid can be collected for making fine cassava starch.
Cassava Pressing Machine(hydraulic press dewater) – Technical Parameter:
Model No.
GD-HP-400
Machine Structure
Single-Column Single-Cylinder
Machine Material
Stainless steel
Capacity
200-300KG/H
Press Frame Volume
400L
Voltage
380V&50/60Hz 3Phase
Power
4.0KW
Cylinder Pressure
15MPa/30t
Interior Casing Dimension
1000×400×1200mm
Dimension(L X W X H)
1250×700×1250mm
Weight
500KG
5. Garri frying machine
This Garri Frying Machine is an important garri processing machine in the whole garri(gari) production line, which can do further dehydration of the cassava flour and can evaporate the poisonous hydrocyanic acid. Add the cassava flour into the frying pot which is a jacketed kettle with electric heating function, and then the inner mixing shaft will rotate for stirring the garri evenly.
When the frying temperature reaches about 50-60℃, the hydrocyanic acid will be evaporated greatly. During this cassava roasting link, we can also add the palm oil for making the yellow garri.
Electric Garri Fryer Machine Technical Parameter:
Model No.
GD-EF-1200
Heating Type
Electric
Power
36KW + 1.5KW
Machine Material
Stainless steel
Capacity
100-150KG/H
Voltage
380V/50Hz 3Phase
Rotate Speed
can be adjusted
Heat Transfer Area
2m2
Operating Temperature
150-180℃
Inner Diameter of Pot
1200mm
Inner Depth of Pot
400mm
Inner Volume of Pot
400L
Weight
850KG
Dimension(L X W X H)
2440×1310×1700mm
6. Garri(gari) powder milling and sieving machine
The garri sieving machine is three-stages screening equipment for sieving out the fine garri powder. Pour the garri onto the screening mash, and the garri flour will be sieved layer by layer through the continuous vibration of this machine. After screening, we can get three kinds of garri powder with different fineness. And the gari with bigger particles can be re-crushed by the crusher machine for fine garri powder.
7. Garri packing machine
The automatic packing machine is a very useful machine for packaging the garri powder into the independent bags quantitatively. The packing amount for each bags is up to your actual requirements. And we can also customize the patterns and letters on the garri packing bags for you.
