CFast YSCS
Yansen CFast YSCS, featured as small form factor, can be configured as a boot device or data storage and is suitable for most industrial applications. With TLC NAND Flash and LDPC ECC, provide high performance and prolong lifespan with exceptional reliability. Supported with hardware write protection, can prevent valuable data on a device from modification and deletion.
Characteristics Of YANSEN CFast YSCS
Flash Type
MLC/TLC
Capacity
8GB~512GB
Sequential Read
Up to 500MB/s
Sequential Write
Up to 300MB/s
4K Random Read
18500 IOPS
4K Random Write
19100 IOPS
Operating Temperature
-20°C ~ 70°C, -40°C ~ 85°C
Storage Temperature
55°C ~ +95°C
Humidity
5%-95% RH non-condensing
Shock
1500G/0.5ms
Vibration
80Hz~2000Hz/20G
Operating Voltage
DC 3.3V±5%
Power Consumption（MAX）
1.5W
Dimensions
L42.8mm*W36.4mm*H3.3mm ±0.15mm
MTBF
2 million hours
Warranty
5-year warranty
Characteristics Of YANSEN CFast YSCS
Flash Type MLC/TLC
Capacity 8GB~512GB
Sequential Read Up to 500MB/s
Sequential Write Up to 300MB/s
4K Random Read 18500 IOPS
4K Random Write 19100 IOPS
Operating Temperature -20°C ~ 70°C, -40°C ~ 85°C
Storage Temperature 55°C ~ +95°C
Humidity 5%-95% RH non-condensing
Shock 1500G/0.5ms
Vibration 80Hz~2000Hz/20G
Operating Voltage DC 3.3V±5%
Power Consumption（MAX） 1.5W
Dimensions L42.8mm*W36.4mm*H3.3mm ±0.15mm
MTBF 2 million hours
Warranty 5-year warranty.
